Best Cooling Solution For Alfresco Areas, Beer Gardens and Domestic Applications
KTW Misting Outdoor Fans are IPX4 rated and exclusive to OZmist. They are the only oscillating fan on the market that are suitable for outdoor use such as commercial alfresco areas, restaurants, beer gardens, sports venues etc.
The options are a stylish gloss black powder coat, or our all new 318 stainless steel finish suits all décors, and the ultra-quiet fan will ensure you keep cool without the noise of our larger variants. The KTW fans feature a 4 bladed fan, making them very quiet while still moving a substantial amount of air. Available in 600mm fan blade diameter (650mm shroud).
Speak to us about the best cooling solution for your venue, available now!
Key Features
| Mist Throw | |||
|---|---|---|---|
|
Mist Throw |
8M - 10M |
Mobility |
Wall Mount |
|
Oscillation |
On/Off Control |
Pump |
N/A |
|
Water tank |
N/A |
Mounting
Unit |
N/A |
Our KTW Misting Fan has two available models – KTW 2460 and KTW 1845, both designed to be used with OZmist’s High-Pressure Pump Module to give the most efficient cooling experience. Pumps provide High-Pressure water to the Misting Nozzles fixed to the face of the fan and expel an Ultra-Fine Mist that will travel further and will evaporate quicker giving you the ultimate cooling solution.
The KTW range of fans come in a Wall Mount option only, each Fan comes fitted with one of our Stainless Steel 6 Nozzle Misting Ring as standard. If a Misting Ring is not required, each KTW Fan can be purchased without the Misting Ring.
The Wall Mount Fan is simple to install, with four bolts to anchor the mounting plate. Once the plate is secured the Fan head can be positioned over the pole, the holes aligned and tightened accordingly. OZmist recommends that both KTW Fans be installed at a minimum height of 2200mm, measuring from the centre of the Fan to the ground. And that there be at least 250mm between the top of the Fan cage and any ceilings or obstructions. Everything you need to install the KTW Fan is included in the product box. All KTW fans are covered by a 12-month warranty.
Each Fan has an inline controller with three adjustable speeds to choose from that when not in use slides into the rear of the motor. The Oscillation can be toggled by push/pull switch on top of the Fan Motor.
Yes, it is possible to purchase a KTW Fan without the Stainless Steel Misting Ring and fit one of OZmist’s Low-Pressure Misting Rings instead.
It must be noted that the Low-Pressure Mist Rings can cause wetting on some surfaces.
| Dimensions |
|---|
|
Dimensions |
|
Length: 660mm
Width: 660mm
Height: 300mm |
|
Water Tank Capacity: |
|
N/A |
|
Weight: |
|
Dry Weight: 17kg (per Fan with Stainless Steel Mist Ring) |
| Dimensions |
|---|
|
Flow Rate: |
|
With Stainless Steel Misting Ring 1 x Fan @ 1000psi = 0.336L/pm
|
|
Transport: |
|
N/A |
|
Generator: |
|
230V / 50Hz 0.57A 127W |
|
Speed Max: |
|
3 Speed Levels: Low Medium High |
Key Features
| Mist Throw | |||
|---|---|---|---|
|
Mist Throw |
8M - 10M |
Mobility |
Wall Mount |
|
Oscillation |
On/Off Control |
Pump |
N/A |
|
Water tank |
N/A |
Mounting
Unit |
N/A |
Our KTW Fan Range are designed to work in all environments with the inclusion of an IPX4 Rating these Fans are best suited for outdoor applications. These Fans are fitted with a wide four edge blade that reduces the operation noise of this Fan dramatically compared to other options on the market.
|
Used For Indoor & Outdoor Areas |
Mist Throw 8M - 10M |
|---|---|
|
Tank Size N/A |
Mobility Wall Mount |
|
Used For Indoor & Outdoor Areas |
Mist Throw 8-12m |
|---|---|
|
Tank Size 50L |
Mobility Portable |
|
Used For Indoor & Outdoor Areas |
Mist Throw 9m |
|---|---|
|
Tank Size 70L Portable /8L Wall Mount |
Mobility Portable & Fixed |
|
Used For Indoor & Outdoor Areas |
Mist Throw 10M |
|---|---|
|
Tank Size 190 L |
Mobility Forklift required |
